Saelig Introduces USB Embedded Development Tool

The GP-24100 enables analysis of digital interfaces.

The GP-24100 enables analysis of digital interfaces.

By DE Editors

Saelig Introduces USB Embedded Development Tool

Saelig Company, Inc.’s GP-24100 is a PC-controlled USB 2.0 device featuring arbitrary digital waveform generator (ADWG) and logic analyzer capabilities.

It enables the simulation and analysis of digital interfaces, streaming data to/from a PC to 16 data lines at up to 10MHz, with six additional control lines for repetitive sequence generation, in/out clocking,  or trigger definition.

With its 8MB embedded memory buffer and 100MHz operation on all 16 digital lines, GP-24100 complements conventional lab equipment for digital electronic system design, test, and debug. It has a maximum sustained throughput via USB of up to 30MB/s.

The supplied 8PI Control Panel Software offers graphical scripting (TCL/tk) and programming (C/C++) interfaces to automate tasks and bridge between programming environments and hardware prototypes.

With its ADWG / Pattern Generator mode of operation, the GP-24100 allows users to generate extended depths of arbitrary digital stimuli, directly from a PC through a USB connection and create16 bit-wide arbitrary patterns at up to 100 MHz.

GP-24100’s Analyzer mode of operation transforms the test box into a simple logic analyzer to collect and analyze digital data, sampling 16 bits at up to 100 MHz and storing data in 8 Mbytes of internal memory.

For more information, visit Saelig.

Sources:  Press materials received from the company and additional information gleaned from the company’s website.
